BUILDER: |
Fosen Mek. Verksteder A/S, Norway, NB 62 |
|
OWNER: |
United Shipping Ltd Ab,
Finland |
|
DELIVERED: |
January, 1998 |
|
CLASS: |
DnV + 1A 1, General Cargo
Carrier, Container, Ro/Ro, ICE 1A*, EO, W1-OC, DG-P, TMON, PET, DK(+), Including Finnish
Ice Class 1A super |
|
FLAG: |
Finnish |
|
REGULATIONS: |
World wide traffic |
|
MAIN
PARTICULARS: |
 |
Length Loa |
154.5 m |
|
Breadth Mld |
22.7
m |
|
Draught summer |
6.95 m |
|
DWT, summer
freeboard |
8853
t |
|
Gross Tonnage |
12251 GT |
|
|
CARGO DECK
ACCESSES: |
Two stern ramps, width of
drive way: 13.40 m/4.10 m. Driving ramp between main deck/tanktop and main deck/weather
deck, driving width: 4.10 m |
|
SPEED: |
20.0 knots at 90 MCR, draught 6,95 m. |
|
REEFER
PLUGS: |
40 PC, 10 kW/32 AMPS/380 V |
|
ENDURANCE: |
Min. 10 000 nautical miles at 20.0 kn,
draugh: 6.95 |
|
ACCOMMODATION: |
14 officers and crew
single cabins, 1 pilot and 6 double berth drivers cabins. |
|
MACHINERY |
|
MAIN ENGINE: |
One single
acting, 380 cSt/50ºC 15600 kW - 500 rpm Wärtsilä Vasa 16V46B, turbocharged and
intercooled engine. with cp propeller. |
|
AUX
ENGINES: |
Two
fresh water cooled Mitsubishi S12R. MDO engines abt. 1000kVA: 800kW - 3 x 380V - 50Hz |
|
SHAFT ALTERNATOR: |
abt. 1250kVA -
1000kW - 1500 rpm |
|
BOWTHRUSTER:
|
KaMeWa,
abt. 800kW |
|
SPECIAL OUTFITTING: |
Fin-stabilizers,
Blohm + Voss |
|
|
| CARGO CAPACITY: |
|
Lane
length |
Area |
Free
height |
Deck
load |
Boogie
axel load |
| Tank Top |
410 m |
1250 m² |
4.6 m |
5.0 t/m² |
50 t |
| Main Deck |
695 m |
2150 m² |
5.0 m |
5.0 t/m² |
50 t |
| WeatherDeck |
670 m |
1920 m² |
|
3.0 t/m² |
50 t |
| Total: |
1775 m |
5320 m² |
|
|
|
|
| CONTAINER CAPACITY: |
336 TEU or
162 FEU + 12 TEU |
| MAX DECK CAPACITY: |
116 Eurocontainers á 30 t,
Total: 3480 t |
|
|
