BUILDER: |
Rauma Repola, Rauma Shipyard, Finland, NB
294 |
|
OWNER: |
United Shipping Ltd Ab,
Finland |
|
DELIVERED: |
April, 1985 |
|
CLASS: |
Lloyd´s Register + 100A1,
Ice 1 A, EO. General Cargo Carrier (Ro-Ro). Finnish/Swedish Ice Class 1A |
|
FLAG: |
Finnish |
|
REGULATIONS: |
World wide traffic |
|
MAIN PARTICULARS: |
 |
Length Loa |
134,6 m |
|
Breadth Mld |
21,0
m |
|
Draught summer |
6,7 m |
|
DWT, summer
freeboard |
9334
t |
|
Gross Tonnage |
10215 GT |
|
|
CARGO DECK
ACCESSES: |
Stern ramp/door, width of
driveway 13,0 m. Two sideloading-openings on starboard side, each provided with one
loading table and two lifts, 3 x 3m, with conveyors for automatic transfer of cargo, max
load 10 t, working range: Tanktop to 13 m above. Lift platform, 18,0 x 4,2 m, workingrange
between tanktop-main deck and weather deck |
|
SPEED: |
Service speed fully loaded/ballast abt.
14,5/15,5 knots on abt. 21 t IF380 |
|
ACCOMMODATION: |
9 single berth cabins, 9
crew and 1 pilot cabin |
|
MACHINERY |
|
MAIN ENGINE: |
Wärtsilä Vasa
16V32. 5520 kW |
|
PROPELLER: |
KaMeWa
cp propeller |
|
REDUCTION GEAR: |
Tacke HSU-900C |
|
AUX
ENGINES: |
3
off Caterpillar 3408 DI each off 294 kW. Generators Stamford, each off 344 kVA |
|
SHAFT GENERATOR: |
1 off Stamford,
900 kVA |
|
BOWTHRUSTER:
|
1
off KaMeWa, 590 kW |
|
|
| CARGO CAPACITY: |
|
Lane
length |
Area |
Free
height |
Deck
load |
Boggie
axel load |
| Tank Top |
387 m |
1267 m² |
4,0 m |
5,0 t/m² |
50 t |
| Main Deck |
580 m |
1852 m² |
6,2 m |
5,0 t/m² |
50 t |
| WeatherDeck |
475 m |
|
|
1,5 t/m² |
50 t |
| Total: |
1442 m |
3119 m² |
|
|
|
|
| CONTAINER CAPACITY: |
|
TEU |
TIERS |
| Tank Top |
43 |
1 |
| Main Deck |
194 |
2 |
| Weather Deck |
160 |
2 (1 empty) |
| Total: |
397 |
|
|
|
|
